ELIA PL - ON/OFF - M1 - OPAL OPTIC - CRI 80 4000 K - IP65 - CLASS II
Code:
GWF1910LA840
Range: ELIA PL
LED Panel
ELIA is the family of GEWISS products designed for fast and easy installation and with a 5 year guarantee. ELIA PL - Panel LED - is the recessed panel for office and workplace lighting. Luminance and glare control, energy efficiency and comfort are the benefits of this product, for the perfect replacement of traditional lighting installations.
-
IP65
IK03
650 °C
Technical Info
Information
Download
Video
Certificates
GENERAL INFORMATION
-
OPTIC AND ILLUMINATING FEATURES
-
Context
High-humidity interiors
Optic
Wide opal
Luminaire
Modular LED luminaire
Unified Glare Rating
UGR < 22
Application
Internal
Lumen output (lm)
3600
Unique digital code
(Datamatrix)
Currently not present
Efficacy
(lm/W) 100
(lm/W) 100
Colour
White
Colour temperature
4000 K
Type of light source
LED
Colour Rendering Index
CRI 80
System power
36 W
Standard Deviation Colour Matching
SDCM ≤ 6
LED Lifetime
L80B50 (Tq25°) = 50.000h
Photobiological Risk Class
RG1
Weight (kg)
3.31
Standard
EN 60598-1; EN 60598-2-2; IEC/TR 62778; EN 62493
Warranty
5 years
ELETRICAL AND LIGHTING FEATURES
-
Stocking temperature
-20° +65°
Supply voltage
200-240 V
Operating temperature
-20° +45°
Rated frequency (Hz)
50 - 60 Hz
MATERIALS
-
Driver
External IP65 driver - Included
Body
Aluminium
Driver failure rate
F025 (Tq=25°C) = 50.000 h
Shield type
PMMA + PS
Overvoltage protection
DM 2 kV
Optic
High-diffusion opalescent diffuser
Control System
ON / OFF
Gasket
-
INSTALLATION AND MAINTENANCE
-
Locking Hook
-
Mounting and installation
Recessed (ceiling-mounted and hanging require separately ordered accessories)
External screw
Stainless steel
Tilt
With suspension adjustment Kit
Colour
Powder coating
Wiring
With power cable
STANDARDS AND APPROVALS
-
Fixing
Free-standing or via separately ordered accessories
Classification
-
Light souce replaceability
Non-replaceable
Device with reduced surface temperature
-
Controlgear replaceability
By professional
DIN 18032-3 certification
-
Driver Box
-
IPEA
-
Maximum surface exposed to the wind
-
Insulation class
II
-
-
IP degree
IP65
-
-
Mechanical resistance
IK03
-
-
Glow Wire Test
650 °C
-
-
Ware Number
94051190
