GENERAL INFORMATION
-
OPTIC AND ILLUMINATING FEATURES
-
Context
Lighting of warehouses, indoor parking and industrial production rooms
Optic
Wide opal
Luminaire
LED luminaire with high lumen power
Unified Glare Rating
-
Application
Internal
Lumen output (lm)
5700
Unique digital code
(Datamatrix)
Currently not present
Efficacy
(lm/W)
122
Colour
White
Colour temperature
4000 K
Type of light source
LED
Colour Rendering Index
CRI>80
System power
47 W
Standard Deviation Colour Matching
SDCM = 3
LED Lifetime
L80 B50 (Tq25°) = 54.000h
Photobiological Risk Class
RG0
Weight (kg)
2
Standard
-
Warranty
5 years
ELETRICAL AND LIGHTING FEATURES
-
Stocking temperature
-
Supply voltage
220 - 240 V
Operating temperature
-25 +40 °C
Rated frequency (Hz)
50 / 60
MATERIALS
-
Driver
Included
Body
Polycarbonate
Driver failure rate
F05 = 50.000h Tq 25°C
Shield type
Polycarbonate
Overvoltage protection
-
Optic
-
Control System
Stand Alone - On / Off
Gasket
-
INSTALLATION AND MAINTENANCE
-
Locking Hook
-
Mounting and installation
Ceiling - Wallmounting - Suspension
External screw
-
Tilt
-
Colour
PC coloured
Wiring
Cable gland with terminal
STANDARDS AND APPROVALS
-
Fixing
-
Classification
-
Light souce replaceability
-
Device with reduced surface temperature
Compliant
Controlgear replaceability
-
DIN 18032-3 certification
-
Driver Box
Built-in
IPEA
-
Maximum surface exposed to the wind
-
Insulation class
I
-
-
IP degree
IP66
-
-
Mechanical resistance
IK08
-
-
Glow Wire Test
850 °C
-
-
Ware Number
94051140
