FIXED INTERLOCKED HORIZONTAL SOCKET-OUTLET - WITHOUT BOTTOM - WITH FUSE-HOLDER BASE - 3P+N+E 32A 200-250V - 50/60HZ 9H - IP44
Code:
GW66139
Range: IB Range
Interlocked socket-outlets IEC 309 standard
Interlocked socket-outlets IEC 309 standard
System of industrial socket-outlets for power distribution in the industrial and commercial sector, equipped with locking device, enabling the most varied professional requirements of installers and panel builder to be met. The IB range is composed of 4 product lines: IP67 standard vertical socket-outlets, IP66 vertical socket-outlets for heavy duty applications, IP44 horizontal socket-outlets and IP44 and IP55 compact socket-outlets.
125 °C
IP44
IK08
850 °C (active parts) - 650 °C (passive parts)
Technical Info
Information
Download
Software
Certificates
Related products
Gewiss Code
Rated current (A)
No. of poles
Rated voltage
Colour
Fuses holder
Reference h
EQUIPMENT AND NOTES
CHARACTERISTIC: compatible with ND fuses, except for versions 16A - 500V that have to accomodate GG cylindrical fuses ø 10,3x38 mm and version 32A - 500V that have to accommodate GG cylindrical fuses ø 14x51 mm.
