JUNCTION BOX WITH PLAIN PRESS-ON LID - IP44 - INTERNAL DIMENSIONS 80X80X40 - WALLS WITH CABLE GLANDS - GREY RAL 7035

Code: GW44003

Range: 44 CE Range
Technopolymer surface-mounting watertight junction boxes

The 44 CE junction boxes range consists of 3 families made of different technopolymers (two of which are Halogen Free) and available in 11 sizes with an ordinary or high-capacity base, high or low lids, blank or transparent lids, smooth walls or with quick-entry cable glands.

IP44

IK07

650 °C

85 °C

Technical Info

Information

Download

Software

Certificates

Insulation class II (according to IEC 61140 standards)

Colour Grey RAL 7035

IP degree IP44

Material Technopolymer GWPLAST 75

Mechanical resistance IK07

Internal dim. LxHxD (mm) 80x80x40

Entries No. holes / Ø 6 / 23

Application Ordinary junctions

Glow Wire Test 650 °C

Lid Plain press-on

Operating temperature -25 +60 °C

Type of material Halogen-free in compliance with EN 60754-2

Electrocod 02210

Thermo-pressure with ball 85 °C

Walls With cable glands

Accessories for insulation restoring GW44622

Ware Number 85381000

Product Data Sheet

Technical characteristics

DXF drawing

Go to download area Go to download area

AUTOCAD Plugin

Plugin with GEWISS products for the software AUTOCAD®

REVIT Plugin

Plugin with GEWISS products for the design software REVIT®

PRICE

Estimation of electrical systems

CADpro

Advanced design of electrical systems

Go to software area Go to software area

CE marking

Display the certificate

REACH information

EQUIPMENT AND NOTES

NOTES: to restore the double insulation and original IP degree of protection of the boxes, use the isolating screwcaps.
CHARACTERISTICS: IP 44 boxes with IK07 impact resistance.
The external part of the junction box bottom is provided of central threaded seat. Quick entry cable glands for cables with Ø from 4 to 14 mm and tubes with Ø 16, 20 mm. pressure closing lid.
