HOME GATEWAY - 100-240 V ac 50/60 Hz - 2 MODULES - SATIN WHITE - CHORUSMART

Code: GW15840
Range: Connected SMART HOME
Connected Smart Home system
The connected system, based on the Zigbee wireless protocol, offers a full range of solutions for smart homes and small offices that are suitable for both new buildings and renovations.
It enables you to control safety, comfort and consumption, through a unique user experience, using the Home Gateway APP and EGO Smart plates. The system integrates with the Google Home IoT platforms, Amazon Alexa and IFTTT, and all functions can be controlled with Google and Alexa voice assistants.

IP20

Technical Info

Information
Download
Software
Video
Certificates
Colour Satin White
Description Multiprotocol gateway
Power supply 100 ÷ 240 V ac - 50/60 Hz
No. modules 2
Radio connections Wi-Fi (IEEE 802.11 b/g/n), Zigbee (IEEE 802.15.4)
Configuration Throught APP via Cloud
Standard 2014/35/EU, 2014/30/EU, 2014/53/EU, 2011/65/EU, EN 62368-1, EN 303 446-1, EN 301 489-1, EN 301 489-17, EN 55032, EN 55035, EN 300 328, EN 62479
Working temperature -5 ÷ +45 °C
Relative humidity (non-condensative) Max 93%
Power output Zigbee 10 dBm
Dispersible max power (W) 0.7
Wiring terminals With screw
Terminal tightening capacity
stranded cables (mm²)
Max. 1,5
Terminal tightening capacity
solid cables (mm²)
Max. 1,5
IP degree IP20
Ware Number 85389099

Product Data Sheet

Configuration and Use Manual APP (EN)

User guide

Configuration and Use Manual APP (IT)

Disposal

System manual and technical characteristics - IT

System manual and technical characteristics - EN

AUTOCAD Plugin

Plugin with GEWISS products for the software AUTOCAD®

Show more

HOME

Configuration of the home electrical system

Show more

REVIT Plugin

Plugin with GEWISS products for the design software REVIT®

Show more

PRICE

Estimation of electrical systems

Show more

CADpro

Advanced design of electrical systems

Show more

CE marking

Display the certificate

Conformity declaration

EQUIPMENT AND NOTES
CHARACTERISTICS: multiprotocol gateway provided with ZigBee, Wi-Fi and Bluetooth (BLE) interfaces.
APPLICATIONS: the device enables the configuration, supervision, command and control of the smart home installation via the cloud. Management of functions and access to the system’s data is done through a cloud platform, via a dedicated app (smartphone and tablet). System configuration is carried out through this device using the same app.
NOTES: an Internet connection is required in the system. The Bluetooth connection is only used when configuring devices.
