TOUCH DIMMER MODULE - 100-240 V ac - 50/60 Hz - 1 MODULE - CHORUSMART
Code:
GW10923
Range: CHORUSMART - Domestic range
Glossy titanium modular devices
Glossy titanium modular devices
The ChoruSmart modular devices make it possible to create infinite combination between devices and plates, thanks to a complete range that is able to satisfy all design, functional and installation requirements. Available in glossy painted titanium, innovative and trendy, they include rocker button keys with ½, 1 and 2 modules to optimise space, and axial keys in EVO or SMART version for advanced functions. The front attachment system facilitates assembly and release without removing the support.
IP20 (with plate fitted)
Technical Info
Information
Download
Software
Certificates
Description
Dimmer touch
Power supply
100 ÷ 240 V ac - 50/60 Hz
No. modules
1
No. input channels
2
Local control
Via 2 frontal touch areas (must be completed with ICE Touch plate)
Auxiliary input channel voltage
100 ÷ 240 V ac - 50/60 Hz
Stocking temperature
-25 ÷ +70 °C
No. output channels
1
Working temperature
-5 ÷ +45 °C
Relative humidity (non-condensative)
Max 93%
240 V ac Incandescent-halogen lamps
4 ÷ 150 W
Front light signaling
Blue led
240 V ac LED lamps
4-150W (max 10 lamps)
Wiring terminals
With screw
Loads piloted from electronic transf. 240 V ac
4 ÷ 150 VA (240 V ac)
Terminal tightening capacity stranded cables (mm²)
Max. 1,5
240 V Fluorescent lamps
-
Terminal tightening capacity solid cables (mm²)
Max. 1,5
Load control
Trailing edge
Context
Dry indoor places
Acoustic signalling element
Buzzer
IP degree
IP20 (with plate fitted)
Standard
2014/35/EU (LVD), 2014/30/EU (EMC), 2011/65/EU + 2015/863 (RoHS), EN 60669-2-1, EN 60669-1, EN IEC 63000
Ware Number
85365080
EQUIPMENT AND NOTES
CHARACTERISTICS: trailing edge load drive mode (max. 5 lamps). Two touch areas for dimming the connected load. Equipped with 2 inputs for replicating local control of the load via the auxiliary touch 2-command modules GW10925, NO-type buttons, or for creating the centralisation function OFF. The device is equipped with blue LEDs for easy location that can be set to two different light intensity levels. Excludable built-in buzzer, function identification by means of icons on the ICE touch plates.
APPLICATIONS: control of the dimmable load connected to the devices. Centralised OFF function, via dedicated inputs.
NOTE: to avoid overheating, multiple products cannot be installed side-by-side inside in the same enclosure; insert a blanking module between two electronic devices. When installing two dimmers in the same box, the maximum loads controlled by each dimmer must be reduced by 50%. To be completed using ICE touch plates (codes: GW16955CB, GW16955CL, GW16955CN, GW16955CT).
APPLICATIONS: control of the dimmable load connected to the devices. Centralised OFF function, via dedicated inputs.
NOTE: to avoid overheating, multiple products cannot be installed side-by-side inside in the same enclosure; insert a blanking module between two electronic devices. When installing two dimmers in the same box, the maximum loads controlled by each dimmer must be reduced by 50%. To be completed using ICE touch plates (codes: GW16955CB, GW16955CL, GW16955CN, GW16955CT).
