RESIDUAL CURRENT CIRCUIT BREAKER - IDP - 4P 40A IMMUNITY B TYPE Idn=0,03 - 4 MODULES
Code:
GWD4532
Range: 90 RCD Range
Modular circuit breakers for residual current protection
The 90 RCD range meets any ground fault protection requirement for any area of application.
The range comprises MDC compact residual current c.b. with overcurrent protection. (from 6 to 32 A, curves B and C, up to 10 kA and lΔn from 30 and 300 mA type AC, A, A[IR] and A[S] and F) BD and BDHP, add-on residual current devices for circuit breakers MT and MTHP (lΔn from 10 mA to 3 A type AC, A, A[IR], A[S] and A adjustable) IDP residual current circuit breakers (up to 125 A, lΔn from 10 to 500 mA type AC, A, A[IR], A[S], F, B).
The range comprises MDC compact residual current c.b. with overcurrent protection. (from 6 to 32 A, curves B and C, up to 10 kA and lΔn from 30 and 300 mA type AC, A, A[IR] and A[S] and F) BD and BDHP, add-on residual current devices for circuit breakers MT and MTHP (lΔn from 10 mA to 3 A type AC, A, A[IR], A[S] and A adjustable) IDP residual current circuit breakers (up to 125 A, lΔn from 10 to 500 mA type AC, A, A[IR], A[S], F, B).
Technical Info
Information
Download
Software
Certificates
Description
RESIDUAL CURRENT CIRCUIT BREAKER
Code
IDP
No. of poles
4P
No. modules
4
Rated current
40 A
Rated residual operating current
30 mA
Type
B
Rated voltage (EN/IEC 61008-1, 61008-2-1, 62423)
400/415 V
Standard
IEC/EN 61008-1, IEC/EN 61008-2-1, IEC/EN 62423
Rated frequency (Hz)
50/60 Hz
Insulation voltage (Ui)
500 V
Rated impulse withstand voltage (Uimp)
4 kV
Overvoltage category
III
Level of immunity (8/20 μs)
3000 A
Section rigid cable
<35
Section flexible cable
<35
Rated tightening torque
3 Nm
Double connection
YES (up stream and down stram)
Operating temperature
-25 +60°C (˃ 40°C with derating)
Stocking temperature
-40°C ÷ +70°C
Electrical endurance
≥ 10.000
Mechanical endurance
≥ 20000
Auxiliaries compatibility
Yes
ReStart compatibility
Yes
Assembly position
Any
Ware Number
85362010
EQUIPMENT AND NOTES
CHARACTERISTICS: type B presents greater resistance to mains disturbances and atmospheric discharges in comparison to standard residual current circuit breakers. Immunity level 8/20 µs is 3000 A.
