90 ReStart Range
Automatic reclosing devices

In the event the switch trips, the ReStart devices, after checking the system status, restore the power supply thereby ensuring maximum continuity of service in complete safety.
Available for both residual current circuit breakers and residual current circuit breakers with overcurrent protection, the range is characterized by the Autotest functions, with periodic and automatic control of the residual current protection without interrupting the power supply and PRO with extended control of the system.

See all product
Benefits
Savings on maintenance costs
Savings on maintenance costs
Automatic solution of involuntary disconnections from the electrical power supply and automated checking of the circuit breaker significantly reduce the need for manual intervention by technicians, which means a reduction in operating costs.
Continuous power supply
Continuous power supply
The ReStart devices automatically restore the power supply if the circuit breaker is unexpectedly tripped. This means less interruption of activities and increased continuity of service, especially in environments where a reliable power supply is critical.
Improved safety
Improved safety
The ReStart automatic reclosing devices prevent dangerous situations because they quickly identify faults in the electrical system and restore the power supply under optimal safety conditions only.

The products of this series

46 products

ReStart Autotest

ReStart Autotest 2 poles - Versions coupled with RCCB's

Category
Automatic reset devices with insulation check and test - PRO

Change category

Automatic reset devices with insulation check and test - PRO
Cod Gewiss
Rated current
Idn
Type of RCCB
Rated voltage
No. of modules EN 50022
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 2 POLES - 25 A TYPE A[IR] Idn=0,03 A 230 V ac - 5 MODULES EN 50022
GW90901N
25 A
30 mA
A[IR]
230 V
5
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 2 POLES - 25 A TYPE B[IR] Idn=0,03 A 230 V ac - 7 MODULES EN 50022
GW90911B
25 A
30 mA
B
230 V
7
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 2 POLES - 40 A TYPE A[IR] Idn=0,03 A 230 V ac - 5 MODULES EN 50022
GW90902N
40 A
30 mA
A[IR]
230 V
5
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 2 POLES - 40 A TYPE B[IR] Idn=0,03 A 230 V ac - 7 MODULES EN 50022
GW90912B
40 A
30 mA
B
230 V
7
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 2 POLES - 63 A TYPE A[IR] Idn=0,03 A 230 V ac - 5 MODULES EN 50022
GW90913
63 A
30 mA
A[IR]
230 V
5

ReStart Autotest 4 poles - Versions coupled with RCCB's

Category
Automatic reset devices with insulation check and test - PRO

Change category

Automatic reset devices with insulation check and test - PRO
Cod Gewiss
Rated current
Idn
Type of RCCB
Rated voltage
No. of modules EN 50022
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 4 POLES - 25 A TYPE A[IR] Idn=0,03 A 400 V - 7 MODULES EN 50022
GW90921
25 A
30 mA
A[IR]
400 V
7
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 4 POLES - 25 A TYPE B[IR] Idn=0,03 A 400 V - 7 MODULES EN 50022
GW90921B
25 A
30 mA
B
400 V
7
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 4 POLES - 40 A TYPE A[IR] Idn=0,03 A 400 V - 7 MODULES EN 50022
GW90922
40 A
30 mA
A[IR]
400 V
7
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 4 POLES - 40 A TYPE B[IR] Idn=0,03 A 400 V - 7 MODULES EN 50022
GW90922B
40 A
30 mA
B
400 V
7
RESTART WITH AUTOTEST PRO - COUPLED WITH RCCB'S - 4 POLES - 63 A TYPE A[IR] Idn=0,03 A 400 V - 7 MODULES EN 50022
GW90923
63 A
30 mA
A[IR]
400 V
7
You saw 22 products on 46
Show others
