SERIES DETAIL
GW FIT Range<br />Accessories for electrical installation

GW FIT Range
Accessories for electrical installation

Cable glands

Nylon cable glands - PG pitch - grey RAL 7035 - IP66
Nylon cable glands - PG pitch - grey RAL 7035 - IP66
Gewiss Code
PG pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss Code GW52001
PG pitch 7
Mounting hole Ø (mm) 12.5
For cables Ø (mm) from 3 to 6
Go
Gewiss Code GW52002
PG pitch 9
Mounting hole Ø (mm) 16
For cables Ø (mm) from 6 to 8
Go
Gewiss Code GW52003
PG pitch 11
Mounting hole Ø (mm) 19
For cables Ø (mm) from 8 to 10.5
Go
Gewiss Code GW52004
PG pitch 13.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 9 to 12.5
Go
Gewiss Code GW52005
PG pitch 16
Mounting hole Ø (mm) 23
For cables Ø (mm) from 13 to 16
Go
Gewiss Code GW52006
PG pitch 21
Mounting hole Ø (mm) 29
For cables Ø (mm) from 9 to 10/from 17 to 20
Go
Gewiss Code GW52007
PG pitch 29
Mounting hole Ø (mm) 37
For cables Ø (mm) from 13.5 to 15/from 21 to 26
Go
Gewiss Code GW52008
PG pitch 36
Mounting hole Ø (mm) 48
For cables Ø (mm) from 17 to 20/from 30 to 34
Go
Gewiss Code GW52009
PG pitch 42
Mounting hole Ø (mm) 54
For cables Ø (mm) from 36 to 39/from 40 to 43
Go
Gewiss Code GW52010
PG pitch 48
Mounting hole Ø (mm) 60
For cables Ø (mm) from 38 to 40/from 46 to 50
Go
SEE ALL
EQUIPMENT AND NOTES
Nylon cable glands - PG pitch - grey RAL 7035 - IP68
Nylon cable glands - PG pitch - grey RAL 7035 - IP68
Gewiss Code
PG pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss Code GW52071
PG pitch 7
Mounting hole Ø (mm) 12.5
For cables Ø (mm) from 3.5 to 6.5
Go
Gewiss Code GW52072
PG pitch 9
Mounting hole Ø (mm) 16
For cables Ø (mm) from 4 to 8
Go
Gewiss Code GW52073
PG pitch 11
Mounting hole Ø (mm) 19
For cables Ø (mm) from 5 to 10
Go
Gewiss Code GW52074
PG pitch 13.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 6 to 12
Go
Gewiss Code GW52075
PG pitch 16
Mounting hole Ø (mm) 23
For cables Ø (mm) from 10 to 14
Go
Gewiss Code GW52076
PG pitch 21
Mounting hole Ø (mm) 29
For cables Ø (mm) from 13 to 18
Go
Gewiss Code GW52077
PG pitch 29
Mounting hole Ø (mm) 37
For cables Ø (mm) from 18 to 25
Go
Gewiss Code GW52078
PG pitch 36
Mounting hole Ø (mm) 48
For cables Ø (mm) from 22 to 32
Go
Gewiss Code GW52079
PG pitch 42
Mounting hole Ø (mm) 54
For cables Ø (mm) from 30 to 38
Go
Gewiss Code GW52080
PG pitch 48
Mounting hole Ø (mm) 60
For cables Ø (mm) from 34 to 44
Go
SEE ALL
EQUIPMENT AND NOTES
Nylon cable glands - METRIC pitch - grey RAL 7035 - IP68
Nylon cable glands - METRIC pitch - grey RAL 7035 - IP68
Gewiss Code
ISO pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss Code GW52042
ISO pitch 12x1.25
Mounting hole Ø (mm) 12
For cables Ø (mm) from 3 to 6.5
Go
Gewiss Code GW52043
ISO pitch 16x1.5
Mounting hole Ø (mm) 16
For cables Ø (mm) from 5 to 10
Go
Gewiss Code GW52044
ISO pitch 20x1.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 10 to 14
Go
Gewiss Code GW52045
ISO pitch 25x1.5
Mounting hole Ø (mm) 25
For cables Ø (mm) from 13 to 18
Go
Gewiss Code GW52046
ISO pitch 32x1.5
Mounting hole Ø (mm) 32
For cables Ø (mm) from 18 to 25
Go
Gewiss Code GW52047
ISO pitch 40x1.5
Mounting hole Ø (mm) 40
For cables Ø (mm) from 22 to 32
Go
Gewiss Code GW52048
ISO pitch 50x1.5
Mounting hole Ø (mm) 50
For cables Ø (mm) from 30 to 38
Go
Gewiss Code GW52049
ISO pitch 63x1.5
Mounting hole Ø (mm) 63
For cables Ø (mm) from 35 to 44
Go
EQUIPMENT AND NOTES
Nylon cable glands - PG pitch with housing for rigid conduit - grey RAL 7035 - IP66
Nylon cable glands - PG pitch with housing for rigid conduit - grey RAL 7035 - IP66
Gewiss Code
PG pitch
Mounting hole Ø (mm)
For external conduits (mm)
For cables Ø (mm)

Gewiss Code GW52024
PG pitch 13.5
Mounting hole Ø (mm) 20
For external conduits (mm) 16
For cables Ø (mm) from 9 to 12.5
Go
Gewiss Code GW52025
PG pitch 16
Mounting hole Ø (mm) 23
For external conduits (mm) 20
For cables Ø (mm) from 13 to 16
Go
Gewiss Code GW52026
PG pitch 21
Mounting hole Ø (mm) 29
For external conduits (mm) 25
For cables Ø (mm) from 9 to 10/from 17 to 20
Go
Gewiss Code GW52027
PG pitch 29
Mounting hole Ø (mm) 37
For external conduits (mm) 32
For cables Ø (mm) from 13.5 to 15/from 21 to 26
Go
Gewiss Code GW52028
PG pitch 36
Mounting hole Ø (mm) 48
For external conduits (mm) 40
For cables Ø (mm) from 17 to 20/from 30 to 34
Go
Gewiss Code GW52029
PG pitch 42
Mounting hole Ø (mm) 54
For external conduits (mm) 50
For cables Ø (mm) from 36 to 39/from 40 to 43
Go
EQUIPMENT AND NOTES
Nylon cable glands - PG pitch - grey RAL 7035 - IP54
Nylon cable glands - PG pitch - grey RAL 7035 - IP54
Gewiss Code
PG pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss Code GW52081
PG pitch 7
Mounting hole Ø (mm) 12.5
For cables Ø (mm) from 4 to 6
Go
Gewiss Code GW52082
PG pitch 9
Mounting hole Ø (mm) 16
For cables Ø (mm) from 4.5 to 7
Go
Gewiss Code GW52083
PG pitch 11
Mounting hole Ø (mm) 19
For cables Ø (mm) from 6 to 9
Go
Gewiss Code GW52084
PG pitch 13.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 9 to 12
Go
Gewiss Code GW52085
PG pitch 16
Mounting hole Ø (mm) 23
For cables Ø (mm) from 11 to 14
Go
Gewiss Code GW52086
PG pitch 21
Mounting hole Ø (mm) 29
For cables Ø (mm) from 14 to 18
Go
Gewiss Code GW52087
PG pitch 29
Mounting hole Ø (mm) 37
For cables Ø (mm) from 18 to 25
Go
Gewiss Code GW52088
PG pitch 36
Mounting hole Ø (mm) 48
For cables Ø (mm) from 26 to 32
Go

Closure caps

Nylon closure caps - grey RAL 7035 - IP65
Nylon closure caps - grey RAL 7035 - IP65
Gewiss Code
Pitch

Gewiss Code GW52361
Pitch PG7
Go
Gewiss Code GW52362
Pitch PG9
Go
Gewiss Code GW52363
Pitch PG11
Go
Gewiss Code GW52364
Pitch PG13.5
Go
Gewiss Code GW52365
Pitch PG16
Go
Gewiss Code GW52366
Pitch PG21
Go
Gewiss Code GW52367
Pitch PG29
Go
Gewiss Code GW52368
Pitch PG36
Go
Gewiss Code GW52369
Pitch PG42
Go
Gewiss Code GW52370
Pitch PG48
Go
Gewiss Code GW52372
Pitch M12
Go
Gewiss Code GW52373
Pitch M16
Go
Gewiss Code GW52374
Pitch M20
Go
Gewiss Code GW52375
Pitch M25
Go
Gewiss Code GW52376
Pitch M32
Go
Gewiss Code GW52377
Pitch M40
Go
Gewiss Code GW52378
Pitch M50
Go
Gewiss Code GW52379
Pitch M63
Go
SEE ALL
EQUIPMENT AND NOTES
O-ring for closure caps
O-ring for closure caps
Gewiss Code
For caps with pitch

Gewiss Code GW52441
For caps with pitch PG7
Go
Gewiss Code GW52442
For caps with pitch PG9
Go
Gewiss Code GW52443
For caps with pitch PG11
Go
Gewiss Code GW52444
For caps with pitch PG13.5
Go
Gewiss Code GW52445
For caps with pitch PG16
Go
Gewiss Code GW52446
For caps with pitch PG21
Go
Gewiss Code GW52447
For caps with pitch PG29
Go
Gewiss Code GW52448
For caps with pitch PG36
Go
Gewiss Code GW52449
For caps with pitch PG42
Go
Gewiss Code GW52450
For caps with pitch PG48
Go
Gewiss Code GW52452
For caps with pitch M12
Go
Gewiss Code GW52453
For caps with pitch M16
Go
Gewiss Code GW52454
For caps with pitch M20
Go
Gewiss Code GW52455
For caps with pitch M25
Go
Gewiss Code GW52456
For caps with pitch M32
Go
Gewiss Code GW52457
For caps with pitch M40
Go
Gewiss Code GW52458
For caps with pitch M50
Go
Gewiss Code GW52459
For caps with pitch M63
Go
SEE ALL

Fixing nuts

Nylon fixing nuts - Grey RAL 7035
Nylon fixing nuts - Grey RAL 7035
Gewiss Code
Pitch

Gewiss Code GW52341
Pitch PG7
Go
Gewiss Code GW52342
Pitch PG9
Go
Gewiss Code GW52343
Pitch PG11
Go
Gewiss Code GW52344
Pitch PG13.5
Go
Gewiss Code GW52345
Pitch PG16
Go
Gewiss Code GW52346
Pitch PG21
Go
Gewiss Code GW52347
Pitch PG29
Go
Gewiss Code GW52348
Pitch PG36
Go
Gewiss Code GW52349
Pitch PG42
Go
Gewiss Code GW52350
Pitch PG48
Go
Gewiss Code GW52352
Pitch M12
Go
Gewiss Code GW52353
Pitch M16
Go
Gewiss Code GW52354
Pitch M20
Go
Gewiss Code GW52355
Pitch M25
Go
Gewiss Code GW52356
Pitch M32
Go
Gewiss Code GW52357
Pitch M40
Go
Gewiss Code GW52358
Pitch M50
Go
Gewiss Code GW52359
Pitch M63
Go
SEE ALL

Couplings and cable-glands

Shockproof polymer conduit/box couplings Grey RAL 7035
Shockproof polymer conduit/box couplings Grey RAL 7035
Gewiss Code
For external conduits (mm)
Mounting hole Ø (mm)
IP with rigid conduit
IP with corrugated conduit

Gewiss Code GW50415
For external conduits (mm) 16
Mounting hole Ø (mm) 20
IP with rigid conduit IP66
IP with corrugated conduit IP54
Go
Gewiss Code GW50416
For external conduits (mm) 20
Mounting hole Ø (mm) 23
IP with rigid conduit IP66
IP with corrugated conduit IP54
Go
Gewiss Code GW50417
For external conduits (mm) 25
Mounting hole Ø (mm) 29
IP with rigid conduit IP66
IP with corrugated conduit IP54
Go
Gewiss Code GW50418
For external conduits (mm) 32
Mounting hole Ø (mm) 37
IP with rigid conduit IP66
IP with corrugated conduit IP54
Go
Gewiss Code GW50419
For external conduits (mm) 40
Mounting hole Ø (mm) 48
IP with rigid conduit IP66
IP with corrugated conduit IP44
Go
Gewiss Code GW50420
For external conduits (mm) 50
Mounting hole Ø (mm) 54
IP with rigid conduit IP66
IP with corrugated conduit IP44
Go
EQUIPMENT AND NOTES
Flexible polymer conduit/box couplings Grey RAL 7035 - IP44
Flexible polymer conduit/box couplings Grey RAL 7035 - IP44
Gewiss Code
For external conduits (mm)
Mounting hole Ø (mm)

Gewiss Code GW50421
For external conduits (mm) 16
Mounting hole Ø (mm) 23
Go
Gewiss Code GW50422
For external conduits (mm) 20
Mounting hole Ø (mm) 23
Go
Gewiss Code GW50423
For external conduits (mm) 20
Mounting hole Ø (mm) 29
Go
Gewiss Code GW50424
For external conduits (mm) 25
Mounting hole Ø (mm) 29
Go
Gewiss Code GW50425
For external conduits (mm) 32
Mounting hole Ø (mm) 37
Go
Gewiss Code GW50426
For external conduits (mm) 40
Mounting hole Ø (mm) 37
Go
Gewiss Code GW50427
For external conduits (mm) 50
Mounting hole Ø (mm) 48
Go
Flexible polymer cable gland - Grey RAL 7035 - IP55
Flexible polymer cable gland - Grey RAL 7035 - IP55
Gewiss Code
For ext. conduits max (mm)
Mounting hole Ø (mm)

Gewiss Code GW50428
For ext. conduits max (mm) 16
Mounting hole Ø (mm) 19
Go
Gewiss Code GW50429
For ext. conduits max (mm) 20
Mounting hole Ø (mm) 23
Go
Gewiss Code GW50430
For ext. conduits max (mm) 25
Mounting hole Ø (mm) 29
Go
Gewiss Code GW50431
For ext. conduits max (mm) 32
Mounting hole Ø (mm) 37
Go
Gewiss Code GW50432
For ext. conduits max (mm) 40
Mounting hole Ø (mm) 48
Go
EQUIPMENT AND NOTES

Cable glands

Nickel-plated brass cable glands - IP65
Nickel-plated brass cable glands - IP65
Gewiss Code
Type of pitch
Seals Ø (mm)

Gewiss Code GW76841
Type of pitch PG11
Seals Ø (mm) 7.5 / 10 / 12.5
Go
Gewiss Code GW76842
Type of pitch PG13.5
Seals Ø (mm) 7.5 / 10 / 12.5
Go
Gewiss Code GW76843
Type of pitch PG16
Seals Ø (mm) 7.5 / 10 / 12.5
Go
Gewiss Code GW76844
Type of pitch PG21
Seals Ø (mm) 10 / 13 / 16 / 19
Go
Gewiss Code GW76845
Type of pitch PG29
Seals Ø (mm) 18 / 21 / 24 / 27
Go
Gewiss Code GW76846
Type of pitch PG36
Seals Ø (mm) 24 / 27 / 30 / 33
Go
Gewiss Code GW76847
Type of pitch PG42
Seals Ø (mm) 30 / 33 / 36 / 39
Go
Gewiss Code GW76848
Type of pitch M20
Seals Ø (mm) 4 / 7 / 10 / 13
Go
Gewiss Code GW76849
Type of pitch M25
Seals Ø (mm) 8.5 / 11.5 / 14.5 / 17.5
Go
Gewiss Code GW76850
Type of pitch M32
Seals Ø (mm) 16 / 19 / 22 / 25
Go
Gewiss Code GW76851
Type of pitch M40
Seals Ø (mm) 23 / 26 / 29 / 32
Go
Gewiss Code GW76852
Type of pitch M50
Seals Ø (mm) 30 / 33 / 36 / 39
Go
SEE ALL
EQUIPMENT AND NOTES
Nickel-plated brass cable glands - IP68
Nickel-plated brass cable glands - IP68
Gewiss Code
Type of pitch
For cables Ø (mm)

Gewiss Code GW76825
Type of pitch PG11
For cables Ø (mm) from 4 to 9
Go
Gewiss Code GW76826
Type of pitch PG13.5
For cables Ø (mm) from 7 to 11
Go
Gewiss Code GW76827
Type of pitch PG16
For cables Ø (mm) from 10 to 13
Go
Gewiss Code GW76828
Type of pitch PG21
For cables Ø (mm) from 12 to 17
Go
Gewiss Code GW76829
Type of pitch PG29
For cables Ø (mm) from 17 to 24
Go
Gewiss Code GW76830
Type of pitch PG36
For cables Ø (mm) from 20 to 26 / from 27 to 34
Go
Gewiss Code GW76897
Type of pitch PG42
For cables Ø (mm) from 32 to 36
Go
Gewiss Code GW76894
Type of pitch M12
For cables Ø (mm) from 3 to 6.5
Go
Gewiss Code GW76896
Type of pitch M16
For cables Ø (mm) from 4 to 9
Go
Gewiss Code GW76831
Type of pitch M20
For cables Ø (mm) from 10 to 13
Go
Gewiss Code GW76832
Type of pitch M25
For cables Ø (mm) from 12 to 17
Go
Gewiss Code GW76833
Type of pitch M32
For cables Ø (mm) from 14 to 21
Go
Gewiss Code GW76834
Type of pitch M40
For cables Ø (mm) from 19 to 27
Go
Gewiss Code GW76835
Type of pitch M50
For cables Ø (mm) from 25 to 34
Go
Gewiss Code GW76895
Type of pitch M63
For cables Ø (mm) from 34 to 48
Go
SEE ALL
EQUIPMENT AND NOTES

Extensions

Nickel-plated brass extensions - IP65
Nickel-plated brass extensions - IP65
Gewiss Code
Male thread
Female thread

Gewiss Code GW76865
Male thread PG11
Female thread PG13.5
Go
Gewiss Code GW76866
Male thread PG13.5
Female thread PG16
Go
Gewiss Code GW76867
Male thread PG16
Female thread PG21
Go
Gewiss Code GW76868
Male thread PG21
Female thread PG29
Go
Gewiss Code GW76869
Male thread PG29
Female thread PG36
Go
Gewiss Code GW76870
Male thread M20
Female thread M25
Go
Gewiss Code GW76871
Male thread M25
Female thread M32
Go
Gewiss Code GW76872
Male thread M32
Female thread M40
Go
Gewiss Code GW76873
Male thread M40
Female thread M50
Go
SEE ALL
EQUIPMENT AND NOTES

Closure caps

Nickel-plated brass closure caps - IP65
Nickel-plated brass closure caps - IP65
Gewiss Code
Type of pitch

Gewiss Code GW76980
Type of pitch PG11
Go
Gewiss Code GW76981
Type of pitch PG13.5
Go
Gewiss Code GW76982
Type of pitch PG16
Go
Gewiss Code GW76983
Type of pitch PG21
Go
Gewiss Code GW76984
Type of pitch PG29
Go
Gewiss Code GW76985
Type of pitch PG36
Go
Gewiss Code GW76986
Type of pitch PG42
Go
Gewiss Code GW76972
Type of pitch M12
Go
Gewiss Code GW76973
Type of pitch M16
Go
Gewiss Code GW76975
Type of pitch M20
Go
Gewiss Code GW76976
Type of pitch M25
Go
Gewiss Code GW76977
Type of pitch M32
Go
Gewiss Code GW76978
Type of pitch M40
Go
Gewiss Code GW76979
Type of pitch M50
Go
Gewiss Code GW76974
Type of pitch M63
Go
SEE ALL
EQUIPMENT AND NOTES

Fixing nuts

Nickel-plated brass fixing nuts
Nickel-plated brass fixing nuts
Gewiss Code
Type of pitch

Gewiss Code GW76957
Type of pitch PG11
Go
Gewiss Code GW76958
Type of pitch PG13.5
Go
Gewiss Code GW76959
Type of pitch PG16
Go
Gewiss Code GW76960
Type of pitch PG21
Go
Gewiss Code GW76961
Type of pitch PG29
Go
Gewiss Code GW76962
Type of pitch PG36
Go
Gewiss Code GW76963
Type of pitch PG42
Go
Gewiss Code GW76966
Type of pitch M12
Go
Gewiss Code GW76951
Type of pitch M16
Go
Gewiss Code GW76952
Type of pitch M20
Go
Gewiss Code GW76953
Type of pitch M25
Go
Gewiss Code GW76954
Type of pitch M32
Go
Gewiss Code GW76955
Type of pitch M40
Go
Gewiss Code GW76956
Type of pitch M50
Go
Gewiss Code GW76967
Type of pitch M63
Go
SEE ALL

Metal cable glands

ATEX cable glands in nickel-plated brass with PG-pitch and long thread - IP68
ATEX cable glands in nickel-plated brass with PG-pitch and long thread - IP68
Gewiss Code
Type of pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss Code GW76901
Type of pitch PG7
Mounting hole Ø (mm) 12.5
For cables Ø (mm) from 3 to 6.5
Go
Gewiss Code GW76902
Type of pitch PG9
Mounting hole Ø (mm) 16
For cables Ø (mm) from 4 to 8
Go
Gewiss Code GW76903
Type of pitch PG11
Mounting hole Ø (mm) 19
For cables Ø (mm) from 5 to 10
Go
Gewiss Code GW76904
Type of pitch PG13.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 6.5 to 12
Go
Gewiss Code GW76905
Type of pitch PG16
Mounting hole Ø (mm) 23
For cables Ø (mm) from 7 to 12
Go
Gewiss Code GW76906
Type of pitch PG21
Mounting hole Ø (mm) 29
For cables Ø (mm) from 13 to 18
Go
Gewiss Code GW76907
Type of pitch PG29
Mounting hole Ø (mm) 37
For cables Ø (mm) from 18 to 25
Go
Gewiss Code GW76908
Type of pitch PG36
Mounting hole Ø (mm) 48
For cables Ø (mm) from 22 to 32
Go
Gewiss Code GW76909
Type of pitch PG42
Mounting hole Ø (mm) 54
For cables Ø (mm) from 32 to 38
Go
Gewiss Code GW76910
Type of pitch PG48
Mounting hole Ø (mm) 60
For cables Ø (mm) from 37 to 44
Go
SEE ALL
EQUIPMENT AND NOTES
ATEX cable glands in nickel-plated brass with metric pitch and long thread - IP68
ATEX cable glands in nickel-plated brass with metric pitch and long thread - IP68
Gewiss Code
Type of pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss Code GW76921
Type of pitch M12
Mounting hole Ø (mm) 12
For cables Ø (mm) from 3 to 6.5
Go
Gewiss Code GW76922
Type of pitch M16
Mounting hole Ø (mm) 16
For cables Ø (mm) from 6 to 10
Go
Gewiss Code GW76923
Type of pitch M20
Mounting hole Ø (mm) 20
For cables Ø (mm) from 10 to 14
Go
Gewiss Code GW76924
Type of pitch M25
Mounting hole Ø (mm) 25
For cables Ø (mm) from 14 to 18
Go
Gewiss Code GW76925
Type of pitch M32
Mounting hole Ø (mm) 32
For cables Ø (mm) from 20 to 25
Go
Gewiss Code GW76926
Type of pitch M40
Mounting hole Ø (mm) 40
For cables Ø (mm) from 22 to 32
Go
Gewiss Code GW76927
Type of pitch M50
Mounting hole Ø (mm) 50
For cables Ø (mm) from 32 to 38
Go
Gewiss Code GW76928
Type of pitch M63
Mounting hole Ø (mm) 63
For cables Ø (mm) from 37 to 44
Go
EQUIPMENT AND NOTES

Fixing nuts

Nickel-plated brass fixing nuts
Nickel-plated brass fixing nuts
Gewiss Code
Type of pitch

Gewiss Code GW76941
Type of pitch PG7
Go
Gewiss Code GW76942
Type of pitch PG9
Go
Gewiss Code GW76957
Type of pitch PG11
Go
Gewiss Code GW76958
Type of pitch PG13.5
Go
Gewiss Code GW76959
Type of pitch PG16
Go
Gewiss Code GW76960
Type of pitch PG21
Go
Gewiss Code GW76961
Type of pitch PG29
Go
Gewiss Code GW76962
Type of pitch PG36
Go
Gewiss Code GW76963
Type of pitch PG42
Go
Gewiss Code GW76943
Type of pitch PG48
Go
Gewiss Code GW76949
Type of pitch M12
Go
Gewiss Code GW76951
Type of pitch M16
Go
Gewiss Code GW76952
Type of pitch M20
Go
Gewiss Code GW76953
Type of pitch M25
Go
Gewiss Code GW76954
Type of pitch M32
Go
Gewiss Code GW76955
Type of pitch M40
Go
Gewiss Code GW76956
Type of pitch M50
Go
Gewiss Code GW76950
Type of pitch M63
Go
SEE ALL

Fixings for conduits

Shockproof polymer saddle snap clip - Grey RAL 7035
Shockproof polymer saddle snap clip - Grey RAL 7035
Gewiss Code
For external conduits (mm)
Wall-conduit axis distance (mm)

Gewiss Code GW50601
For external conduits (mm) 16
Wall-conduit axis distance (mm) 20
Go
Gewiss Code GW50602
For external conduits (mm) 20
Wall-conduit axis distance (mm) 22
Go
Gewiss Code GW50603
For external conduits (mm) 25
Wall-conduit axis distance (mm) 24.5
Go
Gewiss Code GW50604
For external conduits (mm) 32
Wall-conduit axis distance (mm) 28
Go
Gewiss Code GW50628
For external conduits (mm) 40
Wall-conduit axis distance (mm) 32
Go
Gewiss Code GW50629
For external conduits (mm) 50
Wall-conduit axis distance (mm) 37
Go
EQUIPMENT AND NOTES
Shockproof polymer saddle collar clip - Grey RAL 7035
Shockproof polymer saddle collar clip - Grey RAL 7035
Gewiss Code
For external conduits (mm)
Wall-conduit axis distance (mm)

Gewiss Code GW50605
For external conduits (mm) 16
Wall-conduit axis distance (mm) 20
Go
Gewiss Code GW50606
For external conduits (mm) 20
Wall-conduit axis distance (mm) 22
Go
Gewiss Code GW50607
For external conduits (mm) 25
Wall-conduit axis distance (mm) 24.5
Go
Gewiss Code GW50608
For external conduits (mm) 32
Wall-conduit axis distance (mm) 28
Go
Gewiss Code GW50630
For external conduits (mm) 40
Wall-conduit axis distance (mm) 32
Go
Gewiss Code GW50631
For external conduits (mm) 50
Wall-conduit axis distance (mm) 37
Go
EQUIPMENT AND NOTES

Fixings for cables

Shockproof polymer clips with hardened steel pin - Grey RAL 7035
Shockproof polymer clips with hardened steel pin - Grey RAL 7035
Gewiss Code
Colour
For external conduits (mm)
Internal Ø (mm)
Characteristics

Gewiss Code GW50610
Colour Grey RAL 7035
For external conduits (mm) 3-4
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50611
Colour Grey RAL 7035
For external conduits (mm) 5-6
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50612
Colour Grey RAL 7035
For external conduits (mm) 7-8
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50613
Colour Grey RAL 7035
For external conduits (mm) 9-10
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50614
Colour Grey RAL 7035
For external conduits (mm) 11-12
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50615
Colour Grey RAL 7035
For external conduits (mm) 13-14
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50616
Colour Grey RAL 7035
For external conduits (mm) 15-16
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50617
Colour Grey RAL 7035
For external conduits (mm) 19-20
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50618
Colour Grey RAL 7035
For external conduits (mm) 21-22
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50619
Colour Grey RAL 7035
For external conduits (mm) 25-26
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50620
Colour Grey RAL 7035
For external conduits (mm) 31-32
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50621
Colour White
For external conduits (mm) 5-6
Internal Ø (mm) -
Characteristics -
Go
Gewiss Code GW50622
Colour White
For external conduits (mm) 7-8
Internal Ø (mm) -
Characteristics -
Go
SEE ALL
EQUIPMENT AND NOTES

Collars in galvanized steel

Galvanised steel collars M6 thread with 2 screws
Galvanised steel collars M6 thread with 2 screws
Gewiss Code
For external conduits (mm)
Internal Ø (mm)

Gewiss Code GW50801
For external conduits (mm) 10-11
Internal Ø (mm) -
Go
Gewiss Code GW50802
For external conduits (mm) 12-13
Internal Ø (mm) -
Go
Gewiss Code GW50803
For external conduits (mm) 14-15
Internal Ø (mm) -
Go
Gewiss Code GW50804
For external conduits (mm) 16-17
Internal Ø (mm) -
Go
Gewiss Code GW50805
For external conduits (mm) 19-20
Internal Ø (mm) -
Go
Gewiss Code GW50806
For external conduits (mm) 21-22
Internal Ø (mm) -
Go
Gewiss Code GW50807
For external conduits (mm) 25-26
Internal Ø (mm) -
Go
Gewiss Code GW50808
For external conduits (mm) 31-32
Internal Ø (mm) -
Go
Gewiss Code GW50809
For external conduits (mm) 38-40
Internal Ø (mm) -
Go
Gewiss Code GW50810
For external conduits (mm) 48-50
Internal Ø (mm) -
Go
SEE ALL

Clips in galvanized steel

Galvanised steel clips hole 12x6 mm
Galvanised steel clips hole 12x6 mm
Gewiss Code
Internal Ø (mm)
For external conduits (mm)

Gewiss Code GW50811
Internal Ø (mm) -
For external conduits (mm) 10-11
Go
Gewiss Code GW50812
Internal Ø (mm) -
For external conduits (mm) 12-13
Go
Gewiss Code GW50813
Internal Ø (mm) -
For external conduits (mm) 14-15
Go
Gewiss Code GW50814
Internal Ø (mm) -
For external conduits (mm) 16-17
Go
Gewiss Code GW50815
Internal Ø (mm) -
For external conduits (mm) 19-20
Go
Gewiss Code GW50816
Internal Ø (mm) -
For external conduits (mm) 21-22
Go
Gewiss Code GW50817
Internal Ø (mm) -
For external conduits (mm) 25-26
Go
Gewiss Code GW50818
Internal Ø (mm) -
For external conduits (mm) 31-32
Go
Gewiss Code GW50819
Internal Ø (mm) -
For external conduits (mm) 38-40
Go
Gewiss Code GW50820
Internal Ø (mm) -
For external conduits (mm) 48-50
Go
SEE ALL
Galvanised steel U-bolts with two holes
Galvanised steel U-bolts with two holes
Gewiss Code
Hole dimension (mm)
For external conduits (mm)
Internal Ø (mm)

Gewiss Code GW50821
Hole dimension (mm) 7x4
For external conduits (mm) 10-11
Internal Ø (mm) -
Go
Gewiss Code GW50822
Hole dimension (mm) 7x4
For external conduits (mm) 12-13
Internal Ø (mm) -
Go
Gewiss Code GW50823
Hole dimension (mm) 7x4
For external conduits (mm) 14-15
Internal Ø (mm) -
Go
Gewiss Code GW50824
Hole dimension (mm) 7x4
For external conduits (mm) 16-17
Internal Ø (mm) -
Go
Gewiss Code GW50825
Hole dimension (mm) 7x4
For external conduits (mm) 19-20
Internal Ø (mm) -
Go
Gewiss Code GW50826
Hole dimension (mm) 7x4
For external conduits (mm) 21-22
Internal Ø (mm) -
Go
Gewiss Code GW50827
Hole dimension (mm) 7x4
For external conduits (mm) 25-26
Internal Ø (mm) -
Go
Gewiss Code GW50828
Hole dimension (mm) 10x6
For external conduits (mm) 31-32
Internal Ø (mm) -
Go
Gewiss Code GW50829
Hole dimension (mm) 10x6
For external conduits (mm) 38-40
Internal Ø (mm) -
Go
Gewiss Code GW50830
Hole dimension (mm) 10x6
For external conduits (mm) 48-50
Internal Ø (mm) -
Go
SEE ALL

Fixing straps

Dispenser case for electrical installation accessories

Drill milling cutter

Cup drill milling cutter to drill panels
Cup drill milling cutter to drill panels
Gewiss Code
Description

Gewiss Code GW52402
Description Cup drill milling Ø56
Go
EQUIPMENT AND NOTES

RK Unions - Grey RAL 7035

Coupling - IP40
Coupling - IP40
Gewiss Code
Conduits Ø (mm)

Gewiss Code DX40016
Conduits Ø (mm) 16
Go
Gewiss Code DX40020
Conduits Ø (mm) 20
Go
Gewiss Code DX40025
Conduits Ø (mm) 25
Go
Gewiss Code DX40032
Conduits Ø (mm) 32
Go
Gewiss Code DX40040
Conduits Ø (mm) 40
Go
Gewiss Code DX40050
Conduits Ø (mm) 50
Go
Gewiss Code DX40063
Conduits Ø (mm) 63
Go
EQUIPMENT AND NOTES
Tight bend - IP40
Tight bend - IP40
Gewiss Code
Conduits Ø (mm)

Gewiss Code DX40116
Conduits Ø (mm) 16
Go
Gewiss Code DX40120
Conduits Ø (mm) 20
Go
Gewiss Code DX40125
Conduits Ø (mm) 25
Go
Gewiss Code DX40132
Conduits Ø (mm) 32
Go
Gewiss Code DX40140
Conduits Ø (mm) 40
Go
Gewiss Code DX40150
Conduits Ø (mm) 50
Go
Gewiss Code DX40163
Conduits Ø (mm) 63
Go
EQUIPMENT AND NOTES

MORBIDX unions - Grey RAL 7035

Release coupling - IP67
Release coupling - IP67
Gewiss Code
Conduits Ø (mm)

Gewiss Code DX43016
Conduits Ø (mm) 16
Go
Gewiss Code DX43020
Conduits Ø (mm) 20
Go
Gewiss Code DX43025
Conduits Ø (mm) 25
Go
Gewiss Code DX43032
Conduits Ø (mm) 32
Go
Gewiss Code DX43040
Conduits Ø (mm) 40
Go
Gewiss Code DX43050
Conduits Ø (mm) 50
Go
EQUIPMENT AND NOTES
Release narrow radius bend - IP67
Release narrow radius bend - IP67
Gewiss Code
Conduits Ø (mm)

Gewiss Code DX43116
Conduits Ø (mm) 16
Go
Gewiss Code DX43120
Conduits Ø (mm) 20
Go
Gewiss Code DX43125
Conduits Ø (mm) 25
Go
Gewiss Code DX43132
Conduits Ø (mm) 32
Go
Gewiss Code DX43140
Conduits Ø (mm) 40
Go
Gewiss Code DX43150
Conduits Ø (mm) 50
Go
EQUIPMENT AND NOTES
Release conduit-box union - IP67
Release conduit-box union - IP67
Gewiss Code
Conduits Ø (mm)
ISO pitch
For holes Ø (mm)

Gewiss Code DX43216
Conduits Ø (mm) 16
ISO pitch M 16x1.5
For holes Ø (mm) 16
Go
Gewiss Code DX43220
Conduits Ø (mm) 20
ISO pitch M 20x1.5
For holes Ø (mm) 20
Go
Gewiss Code DX43225
Conduits Ø (mm) 25
ISO pitch M 25x1.5
For holes Ø (mm) 25
Go
Gewiss Code DX43232
Conduits Ø (mm) 32
ISO pitch M 32x1.5
For holes Ø (mm) 32
Go
Gewiss Code DX43240
Conduits Ø (mm) 40
ISO pitch M 40x1.5
For holes Ø (mm) 40
Go
Gewiss Code DX43250
Conduits Ø (mm) 50
ISO pitch M 50x1.5
For holes Ø (mm) 50
Go
EQUIPMENT AND NOTES
Release conduit-sheath union - IP65
Release conduit-sheath union - IP65
Gewiss Code
Conduits Ø (mm)
Sheath Ø (mm)

Gewiss Code DX43316
Conduits Ø (mm) 16
Sheath Ø (mm) 12
Go
Gewiss Code DX43320
Conduits Ø (mm) 20
Sheath Ø (mm) 16
Go
Gewiss Code DX43325
Conduits Ø (mm) 25
Sheath Ø (mm) 20
Go
Gewiss Code DX43332
Conduits Ø (mm) 32
Sheath Ø (mm) 25
Go
Gewiss Code DX43340
Conduits Ø (mm) 40
Sheath Ø (mm) 32
Go
Gewiss Code DX43350
Conduits Ø (mm) 50
Sheath Ø (mm) 40
Go
EQUIPMENT AND NOTES
Release conduit-sheath union equal diameter - IP65
Release conduit-sheath union equal diameter - IP65
Gewiss Code
Conduits Ø (mm)
Sheath Ø (mm)

Gewiss Code DX43416
Conduits Ø (mm) 16
Sheath Ø (mm) 16
Go
Gewiss Code DX43420
Conduits Ø (mm) 20
Sheath Ø (mm) 20
Go
Gewiss Code DX43425
Conduits Ø (mm) 25
Sheath Ø (mm) 25
Go
Gewiss Code DX43432
Conduits Ø (mm) 32
Sheath Ø (mm) 28
Go
Gewiss Code DX43440
Conduits Ø (mm) 40
Sheath Ø (mm) 40
Go
EQUIPMENT AND NOTES
LA SVOLTA conduit-conduit union - IP65
LA SVOLTA conduit-conduit union - IP65
Gewiss Code
Conduits Ø (mm)
Working length (mm)

Gewiss Code DX43516
Conduits Ø (mm) 16
Working length (mm) 110
Go
Gewiss Code DX43520
Conduits Ø (mm) 20
Working length (mm) 132
Go
Gewiss Code DX43525
Conduits Ø (mm) 25
Working length (mm) 209
Go
Gewiss Code DX43532
Conduits Ø (mm) 32
Working length (mm) 301
Go
Gewiss Code DX43540
Conduits Ø (mm) 40
Working length (mm) 302
Go
Gewiss Code DX43550
Conduits Ø (mm) 50
Working length (mm) 311
Go

SPEEDY-FLEX couplings - Grey RAL 7035

Watertight flexible couplings - IP66
Watertight flexible couplings - IP66
Gewiss Code
For external conduits (mm)
External Ø (mm)
Internal Ø (mm)
Length (mm)

Gewiss Code GW50201
For external conduits (mm) 16
External Ø (mm) 27
Internal Ø (mm) 13
Length (mm) 140
Go
Gewiss Code GW50202
For external conduits (mm) 20
External Ø (mm) 31.5
Internal Ø (mm) 17
Length (mm) 160
Go
Gewiss Code GW50203
For external conduits (mm) 25
External Ø (mm) 41
Internal Ø (mm) 21.5
Length (mm) 205
Go
Gewiss Code GW50204
For external conduits (mm) 32
External Ø (mm) 55
Internal Ø (mm) 28
Length (mm) 290
Go
Gewiss Code GW50205
For external conduits (mm) 40
External Ø (mm) 65
Internal Ø (mm) 35.5
Length (mm) 400
Go
Gewiss Code GW50206
For external conduits (mm) 50
External Ø (mm) 72
Internal Ø (mm) 44.5
Length (mm) 515
Go
EQUIPMENT AND NOTES
Protected flexible couplings - IP44
Protected flexible couplings - IP44
Gewiss Code
For external conduits (mm)
External Ø (mm)
Internal Ø (mm)
Length (mm)

Gewiss Code GW50207
For external conduits (mm) 16
External Ø (mm) 24
Internal Ø (mm) 13
Length (mm) 135
Go
Gewiss Code GW50208
For external conduits (mm) 20
External Ø (mm) 30
Internal Ø (mm) 17
Length (mm) 160
Go
Gewiss Code GW50209
For external conduits (mm) 25
External Ø (mm) 35
Internal Ø (mm) 21.5
Length (mm) 205
Go
Gewiss Code GW50210
For external conduits (mm) 32
External Ø (mm) 45
Internal Ø (mm) 28
Length (mm) 280
Go
Gewiss Code GW50211
For external conduits (mm) 40
External Ø (mm) 55
Internal Ø (mm) 35.5
Length (mm) 400
Go
Gewiss Code GW50212
For external conduits (mm) 50
External Ø (mm) 65
Internal Ø (mm) 44.5
Length (mm) 515
Go
EQUIPMENT AND NOTES

Accessories

Conduit-bending spring for RK15
Conduit-bending spring for RK15
Gewiss Code
Conduits Ø (mm)

Gewiss Code DX51416
Conduits Ø (mm) 16
Go
Gewiss Code DX51420
Conduits Ø (mm) 20
Go
Gewiss Code DX51425
Conduits Ø (mm) 25
Go
Gewiss Code DX51432
Conduits Ø (mm) 32
Go
Gewiss Code DX51440
Conduits Ø (mm) 40
Go
Gewiss Code DX51450
Conduits Ø (mm) 50
Go
EQUIPMENT AND NOTES

Rotating unions

Straight, revolving coupling device - Metric pitch - IP54
Straight, revolving coupling device - Metric pitch - IP54
Gewiss Code
Colour
Sheath Ø (mm)
ISO pitch

Gewiss Code DX54008
Colour Grey RAL 7035
Sheath Ø (mm) 8
ISO pitch M 12x1.5
Go
Gewiss Code DX54010
Colour Grey RAL 7035
Sheath Ø (mm) 10
ISO pitch M 16x1.5
Go
Gewiss Code DX54012
Colour Grey RAL 7035
Sheath Ø (mm) 12
ISO pitch M 16x1.5
Go
Gewiss Code DX54016
Colour Grey RAL 7035
Sheath Ø (mm) 16
ISO pitch M 20x1.5
Go
Gewiss Code DX54020
Colour Grey RAL 7035
Sheath Ø (mm) 20
ISO pitch M 25x1.5
Go
Gewiss Code DX54022
Colour Grey RAL 7035
Sheath Ø (mm) 22
ISO pitch M 25x1.5
Go
Gewiss Code DX54025
Colour Grey RAL 7035
Sheath Ø (mm) 25
ISO pitch M 32x1.5
Go
Gewiss Code DX54028
Colour Grey RAL 7035
Sheath Ø (mm) 28
ISO pitch M 32x1.5
Go
Gewiss Code DX54032
Colour Grey RAL 7035
Sheath Ø (mm) 32
ISO pitch M 40x1.5
Go
Gewiss Code DX54040
Colour Grey RAL 7035
Sheath Ø (mm) 40
ISO pitch M 50x1.5
Go
Gewiss Code DX54050
Colour Grey RAL 7035
Sheath Ø (mm) 50
ISO pitch M 63x1.5
Go
Gewiss Code DX54108
Colour Black RAL 9005
Sheath Ø (mm) 8
ISO pitch M 12x1.5
Go
Gewiss Code DX54110
Colour Black RAL 9005
Sheath Ø (mm) 10
ISO pitch M 16x1.5
Go
Gewiss Code DX54112
Colour Black RAL 9005
Sheath Ø (mm) 12
ISO pitch M 16x1.5
Go
Gewiss Code DX54116
Colour Black RAL 9005
Sheath Ø (mm) 16
ISO pitch M 20x1.5
Go
Gewiss Code DX54120
Colour Black RAL 9005
Sheath Ø (mm) 20
ISO pitch M 25x1.5
Go
Gewiss Code DX54122
Colour Black RAL 9005
Sheath Ø (mm) 22
ISO pitch M 25x1.5
Go
Gewiss Code DX54125
Colour Black RAL 9005
Sheath Ø (mm) 25
ISO pitch M 32x1.5
Go
Gewiss Code DX54128
Colour Black RAL 9005
Sheath Ø (mm) 28
ISO pitch M 32x1.5
Go
Gewiss Code DX54132
Colour Black RAL 9005
Sheath Ø (mm) 32
ISO pitch M 40x1.5
Go
Gewiss Code DX54140
Colour Black RAL 9005
Sheath Ø (mm) 40
ISO pitch M 50x1.5
Go
Gewiss Code DX54150
Colour Black RAL 9005
Sheath Ø (mm) 50
ISO pitch M 63x1.5
Go
SEE ALL
EQUIPMENT AND NOTES
Straight, revolving coupling device - GAS pitch - IP54
Straight, revolving coupling device - GAS pitch - IP54
Gewiss Code
Colour
Sheath Ø (mm)
GAS pitch

Gewiss Code DX54208
Colour Grey RAL 7035
Sheath Ø (mm) 8
GAS pitch 1/4"
Go
Gewiss Code DX54210
Colour Grey RAL 7035
Sheath Ø (mm) 10
GAS pitch 1/4"
Go
Gewiss Code DX54212
Colour Grey RAL 7035
Sheath Ø (mm) 12
GAS pitch 3/8"
Go
Gewiss Code DX54214
Colour Grey RAL 7035
Sheath Ø (mm) 14
GAS pitch 1/2"
Go
Gewiss Code DX54216
Colour Grey RAL 7035
Sheath Ø (mm) 16
GAS pitch 1/2"
Go
Gewiss Code DX54220
Colour Grey RAL 7035
Sheath Ø (mm) 20
GAS pitch 3/4"
Go
Gewiss Code DX54222
Colour Grey RAL 7035
Sheath Ø (mm) 22
GAS pitch 3/4"
Go
Gewiss Code DX54225
Colour Grey RAL 7035
Sheath Ø (mm) 25
GAS pitch 1"
Go
Gewiss Code DX54228
Colour Grey RAL 7035
Sheath Ø (mm) 28
GAS pitch 1"
Go
Gewiss Code DX54232
Colour Grey RAL 7035
Sheath Ø (mm) 32
GAS pitch 1 1/4"
Go
Gewiss Code DX54235
Colour Grey RAL 7035
Sheath Ø (mm) 35
GAS pitch 1 1/4"
Go
Gewiss Code DX54240
Colour Grey RAL 7035
Sheath Ø (mm) 40
GAS pitch 1 1/2"
Go
Gewiss Code DX54250
Colour Grey RAL 7035
Sheath Ø (mm) 50
GAS pitch 2"
Go
Gewiss Code DX54308
Colour Black RAL 9005
Sheath Ø (mm) 8
GAS pitch 1/4"
Go
Gewiss Code DX54310
Colour Black RAL 9005
Sheath Ø (mm) 10
GAS pitch 1/4"
Go
Gewiss Code DX54312
Colour Black RAL 9005
Sheath Ø (mm) 12
GAS pitch 3/8"
Go
Gewiss Code DX54314
Colour Black RAL 9005
Sheath Ø (mm) 14
GAS pitch 1/2"
Go
Gewiss Code DX54316
Colour Black RAL 9005
Sheath Ø (mm) 16
GAS pitch 1/2"
Go
Gewiss Code DX54320
Colour Black RAL 9005
Sheath Ø (mm) 20
GAS pitch 3/4"
Go
Gewiss Code DX54322
Colour Black RAL 9005
Sheath Ø (mm) 22
GAS pitch 3/4"
Go
Gewiss Code DX54325
Colour Black RAL 9005
Sheath Ø (mm) 25
GAS pitch 1"
Go
Gewiss Code DX54328
Colour Black RAL 9005
Sheath Ø (mm) 28
GAS pitch 1"
Go
Gewiss Code DX54332
Colour Black RAL 9005
Sheath Ø (mm) 32
GAS pitch 1 1/4"
Go
Gewiss Code DX54335
Colour Black RAL 9005
Sheath Ø (mm) 35
GAS pitch 1 1/4"
Go
Gewiss Code DX54340
Colour Black RAL 9005
Sheath Ø (mm) 40
GAS pitch 1 1/2"
Go
Gewiss Code DX54350
Colour Black RAL 9005
Sheath Ø (mm) 50
GAS pitch 2"
Go
SEE ALL
EQUIPMENT AND NOTES
Straight, revolving coupling device - PG pitch - IP54
Straight, revolving coupling device - PG pitch - IP54
Gewiss Code
Colour
Sheath Ø (mm)
PG pitch

Gewiss Code DX54408
Colour Grey RAL 7035
Sheath Ø (mm) 8
PG pitch 7
Go
Gewiss Code DX54410
Colour Grey RAL 7035
Sheath Ø (mm) 10
PG pitch 7
Go
Gewiss Code DX54411
Colour Grey RAL 7035
Sheath Ø (mm) 10
PG pitch 9
Go
Gewiss Code DX54412
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 11
Go
Gewiss Code DX54413
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 13.5
Go
Gewiss Code DX54414
Colour Grey RAL 7035
Sheath Ø (mm) 14
PG pitch 13.5
Go
Gewiss Code DX54416
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 13.5
Go
Gewiss Code DX54417
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 16
Go
Gewiss Code DX54420
Colour Grey RAL 7035
Sheath Ø (mm) 20
PG pitch 21
Go
Gewiss Code DX54422
Colour Grey RAL 7035
Sheath Ø (mm) 22
PG pitch 21
Go
Gewiss Code DX54425
Colour Grey RAL 7035
Sheath Ø (mm) 25
PG pitch 29
Go
Gewiss Code DX54428
Colour Grey RAL 7035
Sheath Ø (mm) 28
PG pitch 29
Go
Gewiss Code DX54432
Colour Grey RAL 7035
Sheath Ø (mm) 32
PG pitch 36
Go
Gewiss Code DX54435
Colour Grey RAL 7035
Sheath Ø (mm) 35
PG pitch 36
Go
Gewiss Code DX54508
Colour Black RAL 9005
Sheath Ø (mm) 8
PG pitch 7
Go
Gewiss Code DX54510
Colour Black RAL 9005
Sheath Ø (mm) 10
PG pitch 7
Go
Gewiss Code DX54511
Colour Black RAL 9005
Sheath Ø (mm) 10
PG pitch 9
Go
Gewiss Code DX54512
Colour Black RAL 9005
Sheath Ø (mm) 12
PG pitch 11
Go
Gewiss Code DX54513
Colour Black RAL 9005
Sheath Ø (mm) 12
PG pitch 13.5
Go
Gewiss Code DX54514
Colour Black RAL 9005
Sheath Ø (mm) 14
PG pitch 13.5
Go
Gewiss Code DX54516
Colour Black RAL 9005
Sheath Ø (mm) 16
PG pitch 13.5
Go
Gewiss Code DX54517
Colour Black RAL 9005
Sheath Ø (mm) 16
PG pitch 16
Go
Gewiss Code DX54520
Colour Black RAL 9005
Sheath Ø (mm) 20
PG pitch 21
Go
Gewiss Code DX54522
Colour Black RAL 9005
Sheath Ø (mm) 22
PG pitch 21
Go
Gewiss Code DX54525
Colour Black RAL 9005
Sheath Ø (mm) 25
PG pitch 29
Go
Gewiss Code DX54528
Colour Black RAL 9005
Sheath Ø (mm) 28
PG pitch 29
Go
Gewiss Code DX54532
Colour Black RAL 9005
Sheath Ø (mm) 32
PG pitch 36
Go
Gewiss Code DX54535
Colour Black RAL 9005
Sheath Ø (mm) 35
PG pitch 36
Go
SEE ALL
EQUIPMENT AND NOTES

Fixed unions

Straight, fixed coupling device - Metric pitch - IP54
Straight, fixed coupling device - Metric pitch - IP54
Gewiss Code
Colour
Sheath Ø (mm)
ISO pitch

Gewiss Code DX56008
Colour Grey RAL 7035
Sheath Ø (mm) 8
ISO pitch M12x1
Go
Gewiss Code DX56010
Colour Grey RAL 7035
Sheath Ø (mm) 10
ISO pitch M16x1.5
Go
Gewiss Code DX56012
Colour Grey RAL 7035
Sheath Ø (mm) 12
ISO pitch M16x1.5
Go
Gewiss Code DX56014
Colour Grey RAL 7035
Sheath Ø (mm) 14
ISO pitch M16x1.5
Go
Gewiss Code DX56016
Colour Grey RAL 7035
Sheath Ø (mm) 16
ISO pitch M20x1.5
Go
Gewiss Code DX56022
Colour Grey RAL 7035
Sheath Ø (mm) -
ISO pitch M25x1.5
Go
Gewiss Code DX56025
Colour Grey RAL 7035
Sheath Ø (mm) 25
ISO pitch M25x1.5
Go
Gewiss Code DX56028
Colour Grey RAL 7035
Sheath Ø (mm) 28
ISO pitch M32x1.5
Go
Gewiss Code DX56040
Colour Grey RAL 7035
Sheath Ø (mm) 40
ISO pitch M40x1.5
Go
Gewiss Code DX56050
Colour Grey RAL 7035
Sheath Ø (mm) 50
ISO pitch M50x1.5
Go
SEE ALL
EQUIPMENT AND NOTES
Straight, fixed coupling device - GAS pitch - IP54
Straight, fixed coupling device - GAS pitch - IP54
Gewiss Code
Colour
Sheath Ø (mm)
GAS pitch

Gewiss Code DX56208
Colour Grey RAL 7035
Sheath Ø (mm) 8
GAS pitch 1/4"
Go
Gewiss Code DX56210
Colour Grey RAL 7035
Sheath Ø (mm) 10
GAS pitch 1/4"
Go
Gewiss Code DX56212
Colour Grey RAL 7035
Sheath Ø (mm) 12
GAS pitch 3/8"
Go
Gewiss Code DX56214
Colour Grey RAL 7035
Sheath Ø (mm) 14
GAS pitch 1/2"
Go
Gewiss Code DX56216
Colour Grey RAL 7035
Sheath Ø (mm) 16
GAS pitch 1/2"
Go
Gewiss Code DX56222
Colour Grey RAL 7035
Sheath Ø (mm) -
GAS pitch 3/4"
Go
Gewiss Code DX56225
Colour Grey RAL 7035
Sheath Ø (mm) 25
GAS pitch 3/4"
Go
Gewiss Code DX56228
Colour Grey RAL 7035
Sheath Ø (mm) 28
GAS pitch 1"
Go
Gewiss Code DX56232
Colour Grey RAL 7035
Sheath Ø (mm) 32
GAS pitch 1 1/4"
Go
Gewiss Code DX56235
Colour Grey RAL 7035
Sheath Ø (mm) 35
GAS pitch 1 1/4"
Go
Gewiss Code DX56240
Colour Grey RAL 7035
Sheath Ø (mm) 40
GAS pitch 1 1/2"
Go
Gewiss Code DX56250
Colour Grey RAL 7035
Sheath Ø (mm) 50
GAS pitch 2"
Go
SEE ALL
EQUIPMENT AND NOTES
Straight, fixed coupling device - PG pitch - IP54
Straight, fixed coupling device - PG pitch - IP54
Gewiss Code
Colour
Sheath Ø (mm)
PG pitch

Gewiss Code DX56408
Colour Grey RAL 7035
Sheath Ø (mm) 8
PG pitch 7
Go
Gewiss Code DX56410
Colour Grey RAL 7035
Sheath Ø (mm) 10
PG pitch 7
Go
Gewiss Code DX56411
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 9
Go
Gewiss Code DX56412
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 11
Go
Gewiss Code DX56413
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 13.5
Go
Gewiss Code DX56414
Colour Grey RAL 7035
Sheath Ø (mm) 14
PG pitch 13.5
Go
Gewiss Code DX56415
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 11
Go
Gewiss Code DX56416
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 13.5
Go
Gewiss Code DX56417
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 16
Go
Gewiss Code DX56422
Colour Grey RAL 7035
Sheath Ø (mm) -
PG pitch 16
Go
Gewiss Code DX56423
Colour Grey RAL 7035
Sheath Ø (mm) -
PG pitch 21
Go
Gewiss Code DX56425
Colour Grey RAL 7035
Sheath Ø (mm) 25
PG pitch 21
Go
Gewiss Code DX56428
Colour Grey RAL 7035
Sheath Ø (mm) 28
PG pitch 29
Go
Gewiss Code DX56432
Colour Grey RAL 7035
Sheath Ø (mm) 32
PG pitch 36
Go
Gewiss Code DX56435
Colour Grey RAL 7035
Sheath Ø (mm) 35
PG pitch 36
Go
Gewiss Code DX56440
Colour Grey RAL 7035
Sheath Ø (mm) 40
PG pitch 42
Go
Gewiss Code DX56450
Colour Grey RAL 7035
Sheath Ø (mm) 50
PG pitch 48
Go
SEE ALL
EQUIPMENT AND NOTES

Conduit-sheath unions

MORBIDX release conduit-sheath union - IP65
MORBIDX release conduit-sheath union - IP65
Gewiss Code
Conduits Ø (mm)
Sheath Ø (mm)

Gewiss Code DX43316
Conduits Ø (mm) 16
Sheath Ø (mm) 12
Go
Gewiss Code DX43320
Conduits Ø (mm) 20
Sheath Ø (mm) 16
Go
Gewiss Code DX43325
Conduits Ø (mm) 25
Sheath Ø (mm) 20
Go
Gewiss Code DX43332
Conduits Ø (mm) 32
Sheath Ø (mm) 25
Go
Gewiss Code DX43340
Conduits Ø (mm) 40
Sheath Ø (mm) 32
Go
Gewiss Code DX43350
Conduits Ø (mm) 50
Sheath Ø (mm) 40
Go
EQUIPMENT AND NOTES
Release conduit-sheath union equal diameter - IP65
Release conduit-sheath union equal diameter - IP65
Gewiss Code
Conduits Ø (mm)
Sheath Ø (mm)

Gewiss Code DX43416
Conduits Ø (mm) 16
Sheath Ø (mm) 16
Go
Gewiss Code DX43420
Conduits Ø (mm) 20
Sheath Ø (mm) 20
Go
Gewiss Code DX43425
Conduits Ø (mm) 25
Sheath Ø (mm) 25
Go
Gewiss Code DX43432
Conduits Ø (mm) 32
Sheath Ø (mm) 28
Go
Gewiss Code DX43440
Conduits Ø (mm) 40
Sheath Ø (mm) 40
Go
EQUIPMENT AND NOTES

Standard type

Standard cable ties in colourless polymer
Standard cable ties in colourless polymer
Gewiss Code
Dimensions LxH (mm)
Tensile stress (daN)
Terminal grip capacity Ø

Gewiss Code GW52231
Dimensions LxH (mm) 2.4x75
Tensile stress (daN) 8
Terminal grip capacity Ø 1.5 - 18 mm
Go
Gewiss Code GW52232
Dimensions LxH (mm) 2.5x96
Tensile stress (daN) 8
Terminal grip capacity Ø 1.5 - 23 mm
Go
Gewiss Code GW52233
Dimensions LxH (mm) 2.5x140
Tensile stress (daN) 8
Terminal grip capacity Ø 1.5 - 35 mm
Go
Gewiss Code GW52234
Dimensions LxH (mm) 2.5x203
Tensile stress (daN) 8
Terminal grip capacity Ø 1.5 - 55 mm
Go
Gewiss Code GW52235
Dimensions LxH (mm) 3.6x150
Tensile stress (daN) 18
Terminal grip capacity Ø 2.5 - 39 mm
Go
Gewiss Code GW52236
Dimensions LxH (mm) 3.6x203
Tensile stress (daN) 18
Terminal grip capacity Ø 2.5 - 55 mm
Go
Gewiss Code GW52237
Dimensions LxH (mm) 3.6x292
Tensile stress (daN) 18
Terminal grip capacity Ø 2.5 - 85 mm
Go
Gewiss Code GW52238
Dimensions LxH (mm) 4.8x190
Tensile stress (daN) 22
Terminal grip capacity Ø 3 - 52 mm
Go
Gewiss Code GW52239
Dimensions LxH (mm) 4.8x280
Tensile stress (daN) 22
Terminal grip capacity Ø 3 - 81 mm
Go
Gewiss Code GW52240
Dimensions LxH (mm) 4.8x368
Tensile stress (daN) 22
Terminal grip capacity Ø 3 - 182 mm
Go
Gewiss Code GW52241
Dimensions LxH (mm) 7.6x380
Tensile stress (daN) 55
Terminal grip capacity Ø 4 - 110 mm
Go
Gewiss Code GW52242
Dimensions LxH (mm) 9.0x610
Tensile stress (daN) 80
Terminal grip capacity Ø 5 - 185 mm
Go
Gewiss Code GW52243
Dimensions LxH (mm) 9.0x914
Tensile stress (daN) 80
Terminal grip capacity Ø 5 - 270 mm
Go
SEE ALL
EQUIPMENT AND NOTES

Heavy-duty

Heavy duty wiring ties - black polymer
Heavy duty wiring ties - black polymer
Gewiss Code
Dimensions LxH (mm)
Tensile stress (daN)
Terminal grip capacity Ø

Gewiss Code GW52251
Dimensions LxH (mm) 2.4x75
Tensile stress (daN) 8
Terminal grip capacity Ø 1.5 - 18 mm
Go
Gewiss Code GW52252
Dimensions LxH (mm) 2.5x96
Tensile stress (daN) 8
Terminal grip capacity Ø 1.5 - 23 mm
Go
Gewiss Code GW52253
Dimensions LxH (mm) 2.5x140
Tensile stress (daN) 8
Terminal grip capacity Ø 1.5 - 35 mm
Go
Gewiss Code GW52254
Dimensions LxH (mm) 2.5x203
Tensile stress (daN) 8
Terminal grip capacity Ø 1.5 - 55 mm
Go
Gewiss Code GW52255
Dimensions LxH (mm) 3.6x150
Tensile stress (daN) 18
Terminal grip capacity Ø 2.5 - 39 mm
Go
Gewiss Code GW52256
Dimensions LxH (mm) 3.6x203
Tensile stress (daN) 18
Terminal grip capacity Ø 2.5 - 55 mm
Go
Gewiss Code GW52257
Dimensions LxH (mm) 3.6x292
Tensile stress (daN) 18
Terminal grip capacity Ø 2.5 - 85 mm
Go
Gewiss Code GW52258
Dimensions LxH (mm) 4.8x190
Tensile stress (daN) 22
Terminal grip capacity Ø 3 - 52 mm
Go
Gewiss Code GW52259
Dimensions LxH (mm) 4.8x280
Tensile stress (daN) 22
Terminal grip capacity Ø 3 - 81 mm
Go
Gewiss Code GW52260
Dimensions LxH (mm) 4.8x368
Tensile stress (daN) 22
Terminal grip capacity Ø 3 - 102 mm
Go
Gewiss Code GW52261
Dimensions LxH (mm) 7.6x380
Tensile stress (daN) 55
Terminal grip capacity Ø 4 - 110 mm
Go
Gewiss Code GW52262
Dimensions LxH (mm) 9.0x610
Tensile stress (daN) 80
Terminal grip capacity Ø 5 - 185 mm
Go
Gewiss Code GW52263
Dimensions LxH (mm) 9.0x914
Tensile stress (daN) 80
Terminal grip capacity Ø 5 - 270 mm
Go
SEE ALL
EQUIPMENT AND NOTES

Re-openable

With eyelet

With plate

Cable ties with identification tag in colourless polymer
Cable ties with identification tag in colourless polymer
Gewiss Code
Dimensions LxH (mm)
Tensile stress (daN)
Terminal grip capacity Ø
Label

Gewiss Code GW52291
Dimensions LxH (mm) 2.5x100
Tensile stress (daN) 8
Terminal grip capacity Ø 5 - 25 mm
Label 25 x 8 crossways
Go
Gewiss Code GW52292
Dimensions LxH (mm) 2.5x110
Tensile stress (daN) 8
Terminal grip capacity Ø 1.5 - 25 mm
Label 25 x 8 double-sided
Go
Gewiss Code GW52293
Dimensions LxH (mm) 2.5x200
Tensile stress (daN) 8
Terminal grip capacity Ø 10 - 50 mm
Label 30 x 15 crossways
Go
Gewiss Code GW52294
Dimensions LxH (mm) 4.6x200
Tensile stress (daN) 22
Terminal grip capacity Ø 10 - 50 mm
Label 28 x 13 lenghtways
Go
EQUIPMENT AND NOTES

Complementary items

Two-way self-adhesive bases in colourless polymer to secure cable ties
Two-way self-adhesive bases in colourless polymer to secure cable ties
Gewiss Code
Description
Outer dim. LxHxD (mm)

Gewiss Code GW52226
Description For ties up to 4.5mm
Outer dim. LxHxD (mm) 19x3.9x19
Go
Gewiss Code GW52227
Description For ties up to 5mm
Outer dim. LxHxD (mm) 28x4.0x28
Go
EQUIPMENT AND NOTES

L.T.R. ties

Outdoor black ties in L.T.R. polyamide 12
Outdoor black ties in L.T.R. polyamide 12
Gewiss Code
Dimensions LxH (mm)
Number of heads
Tensile stress (daN)
Terminal grip capacity Ø

Gewiss Code GW52201
Dimensions LxH (mm) 6x115
Number of heads 1
Tensile stress (daN) 24.5
Terminal grip capacity Ø 5 - 25 mm
Go
Gewiss Code GW52202
Dimensions LxH (mm) 6x180
Number of heads 1
Tensile stress (daN) 24.5
Terminal grip capacity Ø 9 - 45 mm
Go
Gewiss Code GW52203
Dimensions LxH (mm) 6x290
Number of heads 1
Tensile stress (daN) 24.5
Terminal grip capacity Ø 20 - 78 mm
Go
Gewiss Code GW52204
Dimensions LxH (mm) 9x180
Number of heads 1
Tensile stress (daN) 36
Terminal grip capacity Ø 10 - 40 mm
Go
Gewiss Code GW52205
Dimensions LxH (mm) 9x265
Number of heads 2
Tensile stress (daN) 50
Terminal grip capacity Ø 26 - 60 mm
Go
Gewiss Code GW52206
Dimensions LxH (mm) 9x360
Number of heads 2
Tensile stress (daN) 50
Terminal grip capacity Ø 26 - 93 mm
Go
Gewiss Code GW52207
Dimensions LxH (mm) 9x510
Number of heads 2
Tensile stress (daN) 53
Terminal grip capacity Ø 70 - 140 mm
Go
Gewiss Code GW52208
Dimensions LxH (mm) 9x760
Number of heads 2
Tensile stress (daN) 53
Terminal grip capacity Ø 70 - 220 mm
Go
EQUIPMENT AND NOTES

Complementary items

Trailing terminals blocks

Mobile terminal blocks with modular busbars - 450V - T 85°C - Transparent - IP20
Mobile terminal blocks with modular busbars - 450V - T 85°C - Transparent - IP20
Gewiss Code
Type of screw
Max. section flex. cables
Min. section flex. cables
No. poles per bar

Gewiss Code GW44661
Type of screw Slotted
Max. section flex. cables 2.5 mm²
Min. section flex. cables 1 mm²
No. poles per bar 10
Go
Gewiss Code GW44665
Type of screw Slotted
Max. section flex. cables 4 mm²
Min. section flex. cables 1.5 mm²
No. poles per bar 10
Go
Gewiss Code GW44662
Type of screw Slotted
Max. section flex. cables 6 mm²
Min. section flex. cables 2.5 mm²
No. poles per bar 10
Go
Gewiss Code GW44663
Type of screw Slotted
Max. section flex. cables 10 mm²
Min. section flex. cables 4 mm²
No. poles per bar 10
Go
Gewiss Code GW44664
Type of screw Slotted
Max. section flex. cables 16 mm²
Min. section flex. cables 6 mm²
No. poles per bar 5
Go
Gewiss Code GW44666
Type of screw Socket head 5mm
Max. section flex. cables 25 mm²
Min. section flex. cables 10 mm²
No. poles per bar 1
Go
Gewiss Code GW44667
Type of screw Socket head 5mm
Max. section flex. cables 35 mm²
Min. section flex. cables 16 mm²
No. poles per bar 1
Go
EQUIPMENT AND NOTES

Modular terminal blocks

Polymer 12 pole modular terminal blocks with brass terminals - 450V - T 85°C - Black
Polymer 12 pole modular terminal blocks with brass terminals - 450V - T 85°C - Black
Gewiss Code
Max. section flex. cables
Min. section flex. cables
hole Ø
Max load
Outer dim. LxHxD (mm)
Fixing

Gewiss Code GW44601
Max. section flex. cables 2.5 mm²
Min. section flex. cables 0.75 mm²
hole Ø 2.9 mm
Max load 24 A
Outer dim. LxHxD (mm) 95x15x16
Fixing With screw
Go
Gewiss Code GW44602
Max. section flex. cables 4 mm²
Min. section flex. cables 1.5 mm²
hole Ø 3.4 mm
Max load 32 A
Outer dim. LxHxD (mm) 117x17x20
Fixing With screw
Go
Gewiss Code GW44603
Max. section flex. cables 10 mm²
Min. section flex. cables 4 mm²
hole Ø 4.4 mm
Max load 57 A
Outer dim. LxHxD (mm) 141x20x23
Fixing With screw
Go
Gewiss Code GW44604
Max. section flex. cables 16 mm²
Min. section flex. cables 6 mm²
hole Ø 5.8 mm
Max load 76 A
Outer dim. LxHxD (mm) 172x25x32
Fixing With screw
Go
Gewiss Code GW44605
Max. section flex. cables 25 mm²
Min. section flex. cables 10 mm²
hole Ø 7.4 mm
Max load 101 A
Outer dim. LxHxD (mm) 210x34x38
Fixing With screw
Go
