NP 54/55 range Aluminium sill-type and device-mounting trunking systems

NP 54/55 range Aluminium sill-type and device-mounting trunking systems

Anodised aluminium multifunctional trunking and columns, for commercial and advanced commercial applications.
•  Elegant finish, with a sophisticated design.
•  DIN rail integrated at the bottom of the trunking.
•  3 types of dividers.
•  High robustness and stability of the closing thanks to the integrated lid.
•  Floor-mounting mini-columns, ceiling- and false ceiling-mounting.

BR-PVC - Trunking and device holders in PVC with integrated cover

Trunking

Mounting rail for device-mounting and sill-type trunking in PVC - Length: 2 metres
Mounting rail for device-mounting and sill-type trunking in PVC - Length: 2 metres
Gewiss Code
Colour
Dimensions HxL (mm)
Lid size (mm)
Section (mm²)

Gewiss Code NP52006
Colour White RAL 9001
Dimensions HxL (mm) 70x100
Lid size (mm) 80
Section (mm²) 5300
Go
Gewiss Code NP52001
Colour White RAL 9001
Dimensions HxL (mm) 70x130
Lid size (mm) 80
Section (mm²) 7130
Go
Gewiss Code NP52017
Colour White RAL 9001
Dimensions HxL (mm) 70x170
Lid size (mm) 80
Section (mm²) 9410
Go
Gewiss Code NP52007
Colour White RAL 9010
Dimensions HxL (mm) 70x100
Lid size (mm) 80
Section (mm²) 5300
Go
Gewiss Code NP52002
Colour White RAL 9010
Dimensions HxL (mm) 70x130
Lid size (mm) 80
Section (mm²) 7130
Go
Gewiss Code NP52018
Colour White RAL 9010
Dimensions HxL (mm) 70x170
Lid size (mm) 80
Section (mm²) 9410
Go
Gewiss Code NP52008
Colour Grey RAL 7035
Dimensions HxL (mm) 70x100
Lid size (mm) 80
Section (mm²) 5300
Go
Gewiss Code NP52005
Colour Grey RAL 7035
Dimensions HxL (mm) 70x130
Lid size (mm) 80
Section (mm²) 7130
Go
Gewiss Code NP52021
Colour Grey RAL 7035
Dimensions HxL (mm) 70x170
Lid size (mm) 80
Section (mm²) 9410
Go

Routing components

External corner
External corner
Gewiss Code
Colour
Dimensions HxL (mm)
Lid size (mm)

Internal corner
Internal corner
Gewiss Code
Colour
Dimensions HxL (mm)
Lid size (mm)

Flat angle
Flat angle
Gewiss Code
Colour
Dimensions HxL (mm)
Lid size (mm)

T junction
T junction
Gewiss Code
Colour
Dimensions HxL (mm)
Lid size (mm)


Complementary items

Profiling
